24 Fibers 2x MPO/MTP OS2 Singlemode Fiber Optic Cable

$112.52
Polarity :
Cable Length :
$112.52
Tags:

This 2x MTP/MPO trunk cables are designed for a toolless installation with modular cassettes or adapters modules and utilise multi-connector technology for a fast and simple way to grow the network.
These 24 fiber Polarity C MTP backbone cables with female connectors will provide an instant link when used with two standard LC to MTP/MPO cassettes and will require standard A-B duplex patch cords.

Please note: The US Conec MTP® connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors.

Product Specifications

Connector A 2x MTP Female (pinless) Connector B 2x MTP Female (pinless)
Fiber Mode  24 fibers OS2 9/125 μm Wavelength 1310/1550 nm
Single Mode Class OS2 RoHS Compliancy Status Compliant
Polish Type APC to APC Minimum Bend Radius 10 mm
Insertion Loss 0.75 dB Max. (0.35 dB Typ.) Return Loss ≥ 60 dB
Attenuation at 1310 nm ≤ 0.32 dB/km Attenuation at 1550 nm ≤ 0.18 dB/km
Jacket OD 3.0 mm Cable Jacket LSZH
Installation Tensile Load 66 N Long-Term Tensile Load 80/240 N
Storage Temperature -40°C to 85°C Operating Temperature -10°C to 70°C
